AC Sources

AC Sources for any application

AC Sources

AC Sources for any application

Intepro’s AC Sources range from basic, manual control to full-featured, remote control
AFC

AFC

Clean Bulk AC Source & Frequency Converter
AMF

AMF

400Hz Aircraft AC Source
AFV-P

AFV-P

Programmable AC/DC output power source with precision measurement and control
AFV

AFV AFV

Programmable AC source with power ratings up to 2MVA
PAS-F GRID SIMULATOR

PAS-F GRID SIMULATOR

Bi-directional AC Source with four quadrant energy feedback function
PAS-F GRID SIMULATOR

GE+vAC GRID SIMULATOR

Regenerative AC Grid Simulator

AC Sources for any application

The basic manual AC Sources are low-cost leaders and provide various frequency ranges and up to 300kVA of power - a great product where precise manual control and low cost is important. Intepro’s Programmable AC Sources are designed for applications where remote and advanced functionality is a requirement. Intepro’s Programmable AC Sources are perfect for use where Transient Generation, 4-Quadrant control and accurate measurements are important.

Features

AC Source Features & Benefits

Power Industry Needs

With available output power up to 2MW, we provide solutions for AC requirements common within the Aerospace, Manufacturing, Utilities and Alternative/Green Energy Industries. From compact, benchtop to free-standing regenerative grid simulators, Intepro has you covered.

Regenerative bi-directional AC sources available.

AC/DC output source available up to 5000VA allows for multiple uses out of one compact unit.

Benchtop to Laboratory sources available.

AC Source
AFC
  • 0.5KVA - 2MVA
  • Motor Testing
  • Optional RS232 or RS485 remote controlling the output V and Hz (no monitoring available)
  • 47-500Hz Frequency Range
  • 5V-150VL-N and 10V-300VL-N Voltage Range
AC Source
AMF
  • 6 - 3000KVA
  • Military / Aerospace
  • RS485 is Standard
  • 350-450Hz with a 500Hz option Frequency Range
  • 115VL-N +/- 10% Voltage Range
AC Source
AFV-P
  • 600VA - 5000VA
  • Low Power
  • USB, LAN. RS232, RS485
  • 15-1000Hz Frequency Range
  • 115V-150VL-N; 230VL-N +/- 15% Voltage Range
AC Source
AFV
  • 15KVA - 2MVA
  • General Purpose
  • USB, LAN. RS232, RS485
  • 45-500Hz Frequency Range
  • 0V-300VL-N and 0V-600VL-N Voltage Range
AC Source
PAS-F
  • 45KVA - 200 KVA
  • Grid Simulator
  • USB, LAN. RS232, RS485
  • 45-65Hz with a 40-70Hz Option Frequency Range
  • 115V-300VL-N Voltage Range
AC Source
GE+ vAC
  • 7.5kW to 160kW
  • Grid Simulator
  • LAN Ethernet with Open Modbus-TCP protocol
  • 48-62Hz Frequency
  • +15% / -20% (-10% @ Prated)

Offering Superior Technology & Support

Our Request a Quote system automatically gets sent to our sales team, who review your request and find the right person to answer your questions about our AC Sources, DC Power Supplies, or ATE Test Systems, or other software or equipment we offer that you have questions about

Intepro

Additional Info About Intepro AC Sources

The AFV-P offers customers a programmable AC/DC output power source with precision measurement and control. This compact power source comes in four power levels, 600VA, 1250VA, 2500VA and 5000VA, providing clean power with distortion less than 0.3% at 40-100Hz.

The AFV is a programmable AC source used for both R&D and ATE operating environments. It is also over 90% efficient which results in lower operating costs and heat generation. The AFV is ideal for applications which require Voltage and Frequency Transient Generation along with independent phase control.
